Artwork Requirements for Custom Sign Manufacturing

Production artwork must describe a physical object

A logo file prepared for a website or business card may not be ready for routing, cutting or dimensional fabrication. Sign production requires clean vector paths, exact wording, finished dimensions and enough stroke width for the selected material and thickness.

AI, EPS, SVG and vector PDF files are preferred. Fonts should be converted to outlines, duplicate paths removed and colors identified with approved codes. Raster images can be used as references but may require redrawing.

Artwork approval confirms spelling, layout, dimensions and color placement. Mounting, thickness, edge treatment and construction should also be written into the quote rather than assumed from the visual proof.

Sign formats and construction choices

Ai, eps and svg vector files are a practical option. This approach can be adjusted through shape, depth, edge treatment, finish and mounting so it supports either a traditional or contemporary brand.

Vector pdf with fonts outlined are a practical option. It works best when the artwork is simplified to the details that remain readable at the intended size. Extra effects should serve the message rather than compete with it.

High-resolution references that can be redrawn when necessary are a practical option. The quote should state whether the piece is raw, primed or fully finished and whether patterns, holes, studs or other mounting preparation are included.

Details that should be confirmed before production

A frequent planning concern is raster images placed inside a PDF. Clear documentation before production is less expensive than correction after material has been cut or paint has been applied.

A frequent planning concern is hairline strokes and small copy that will not fabricate well. The customer, designer, manufacturer and installer should be working from the same approved revision so no one is relying on an outdated drawing.

A frequent planning concern is RGB or CMYK colors that do not identify physical paint. When the answer depends on site conditions, the local installer or contractor should verify it in the field rather than asking the fabrication shop to guess from a photograph.

Prepare artwork for routing, cutting and assembly

Vector artwork is preferred because paths can be scaled cleanly for routing and laser cutting without turning edges soft or jagged. AI, EPS, SVG and production-ready PDF files are usually the most useful. A small JPG can still help us understand the design, but it may not contain enough information to cut accurate letters or reproduce a logo at sign size.

Fonts should be converted to outlines when possible, and brand colors should be identified with a physical or recognized color standard if the match is important. If a file is incomplete, send it anyway along with a reference image. We can tell you what must be rebuilt before production rather than guessing from a low-resolution preview.

Where this service is commonly used

How a custom sign order moves forward

Information to gather before requesting a quote

A complete request produces a faster and more accurate response. Gather the following details when they are available:

• AI, EPS, SVG or vector PDF
• Fonts converted to outlines
• Final spelling and dimensions
• Paint or brand color references
• Layer and routing instructions
• Site photos and mounting details

Do not worry if every item is not available. Send the best information you have and identify what still needs to be measured or approved. We will explain which missing details are essential before fabrication and which can be decided during the quote process.
